Does the EA DOGXL160-7 support grey scale / gray level?

Does the EA DOGXL160-7 support grey scale / gray level?

Frage:
The EA DOGXL uses the UC1610 controller that supports 2 bit grey scale. Does the grey scale work with the DOGXL?

Antwort:
Yes, that's a good question. Please be informed that also the display supports the 4 grey levels! It's simply not mentioned in the data sheet.

On the other hand - and that's the reason why we do not promote - every grey level does reduce the contrast. And so we suggest to prefer using the full black color, whenever possible.

But for some small issues, it may be senseful to use the grey levels also e.g. for a disabled function. But for the very most display content we
suggest to use the full black&white option.

Here's the link to the controllers user manual UC1610.

Have fun with it!
